The
Astus 16.5 is a 16’2” (4.94m) sport/beach trimaran designed by
VPLP Design (France). She is built since 2016 by
Astus Boats (France). The
Sport version comes as standard with better hardware allowing more possibilities to trim sails.
The
Astus 16.5 is as well listed, on Boat-Specs.com, in
Standard version (
see all the versions compared).
Astus 16.5's main features
Model
Astus 16.5
Version
Sport
Hull type
Trimaran
Category
Coastal sport/beach trimaran
Sailboat builder
Sailboat designer
Country
France
Construction
GRP (glass reinforced polyester):
- Hull: Single skin fiberglass polyester
- Deck: Single skin fiberglass polyester
First built hull
2016
Last built hull
Still in production
Appendages
Centerboard : daggerboard (main hull)
Helm
Single tiller
Rudder
Single transom hung rudder (main hull)
Unsinkable
No
Trailerable
Yes
EC design category
iThe CE design category indicates the ability to cope with certain weather conditions (the sailboat is designed for these conditions)
A: Wind < force 9, Waves < 10m
B: Wind < force 8, Waves < 8m
C: Wind < force 6, Waves < 4m
D: Wind < force 4, Waves < 0,5mC
Standard public price ex. VAT (indicative only)
Astus 16.5's main dimensions
Hull length
16’ 2”4.94 m
Waterline length
16’ 1”4.9 m
Beam (width)
12’ 6”3.8 m
Draft
3’ 7”1.1 m
Draft when appendages up
0’ 8”0.2 m
Mast height from DWL
26’ 11”8.2 m
Folding type
Sliding arms
Overall width folded
8’ 2”2.5 m
Overall length folded
16’ 2”4.94 m
Light displacement (MLC)
463 lb210 kg
Astus 16.5's rig and sails
Upwind sail area
183 ft²17 m²
Downwind sail area
339 ft²31.5 m²
Mainsail area
124 ft²11.5 m²
Jib area
59 ft²5.5 m²
Gennaker area
215 ft²20 m²
Rigging type
Sloop Marconi (square top mainsail) fractional
Mast configuration
Deck stepped mast
Rotating spars
Yes
Number of levels of spreaders
1
Spreaders angle
Swept-back (diamond)
Spars construction
Aluminum spars (carbon fiber spars as an option)
Standing rigging
1x19 strand wire continuous
Astus 16.5's performances
Upwind sail area to displacement
iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds.
The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size.
Upwind: under 18 the ratio indicates a cruise oriented sailboat with limited performances especially in light wind, while over 25 it indicates a fast sailboat.518 ft²/T48.12 m²/T
Downwind sail area to displacement
iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds.
The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size.960 ft²/T89.16 m²/T
Displacement-length ratio (DLR)
iThe Displacement Length Ratio (DLR) is a figure that points out the boat's weight compared to its waterline length. The DLR is obtained by dividing the boat's displacement in tons by the cube of one one-hundredth of the waterline length (in feet).
The DLR can be used to compare the relative mass of different sailboats no matter what their length:
a DLR less than 180 is indicative of a really light sailboat (race boat made for planning), while a DLR greater than 300 is indicative of a heavy cruising sailboat.51
Astus 16.5's auxiliary engine
Engine(s)
1 outboard engine
Engine(s) power
3 HP
Fuel type
Gas
Astus 16.5's accommodations and layout
Cockpit
Open aft cockpit
