RS Vision S

Sailboat specifications

The RS Vision is a 15’1” (4.6m) double handed dinghy designed by Phil Morrisson (United Kingdom). She was built between 2008 and 2017 by RS Sailing (United Kingdom). The S version displays the smallest rig and sail area available on this boat.

The RS Vision is as well listed, on Boat-Specs.com, in XL version (see all the versions compared).

RS Vision's main features

Model
RS Vision
Version
S
Hull type
Monohull
Category
Double handed dinghy
Sailboat builder
Sailboat designer
Sailboat collection
Country
United Kingdom
Construction
Rotomolded:
Sandwich rotomolded Polyethylene 3 layers with foam core (Comptec PE3)
First built hull
2008
Last built hull
2017
Appendages
Centerboard : pivoting centerboard
Helm
Single tiller
Rudder
Single transom hung rudder
Unsinkable
No
Trailerable
Yes
EC design category
 iThe CE design category indicates the ability to cope with certain weather conditions (the sailboat is designed for these conditions)

A: Wind < force 9, Waves < 10m
B: Wind < force 8, Waves < 8m
C: Wind < force 6, Waves < 4m
D: Wind < force 4, Waves < 0,5m
C
Standard public price ex. VAT (indicative only)
About
6 650
 (2016)

RS Vision's main dimensions

Hull length
15’ 1”4.6 m
Beam (width)
5’ 8”1.75 m
Light displacement (MLC)
276 lb125 kg

RS Vision's rig and sails

Upwind sail area
131 ft²12.2 m²
Downwind sail area
233 ft²21.6 m²
Mainsail area
97 ft²9 m²
Genoa area
34 ft²3.2 m²
Asymmetric spinnaker area
136 ft²12.6 m²
Rigging type
Sloop Marconi fractional
Mast configuration
Deck stepped mast
Rotating spars
No
Number of levels of spreaders
1
Spreaders angle
Swept-back
Spars construction
Aluminum spars
Standing rigging
Continuous

RS Vision's performances

Crew
2
PY (Portsmouth Yardstick) rating
 iPortsmouth Yardstick is an empirical rating system allowing small sailboats (dinghies included), of different sizes and designs, to race each other fairly. Therefore, by comparing these values, we can have an indication of the relative speed of 2 boats.
1093
Upwind sail area to displacement
 iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds.

The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size.

Upwind: under 18 the ratio indicates a cruise oriented sailboat with limited performances especially in light wind, while over 25 it indicates a fast sailboat.
525 ft²/T48.8 m²/T
Downwind sail area to displacement
 iThe ratio sail area to displacement is obtained by dividing the sail area by the boat's displaced volume to the power two-thirds.

The ratio sail area to displacement can be used to compare the relative sail plan of different sailboats no matter what their size.
930 ft²/T86.4 m²/T

RS Vision's auxiliary engine

Engine(s)
Outboard engine
Engine(s) power
4 HP

RS Vision's accommodations and layout

Cockpit
Aft cockpit
Have you spotted incorrect data?  You can report it in the forum or contact the webmaster
